German Type Coarse Powder Crusher

German Type Coarse Powder Crusher is widely used in the current mining market. It is available for Cement, coal , power plant desulfurization, metallurgy, chemical industry, non-metallic mineral, construction material, ceramics.

Application:Especially for mining, building materials, chemicals, metallurgical industry with the broken materials.

German Type Coarse Powder Crusher

Introduction

The German type coarse powder crusher is widely used to crush mineral ores mediumly or finely with compressive stress below 320Mpa in industries like metallurgy, mining, chemicals, cement, construction, refractory, ceremic, etc.

German Type Coarse Powder Crusher

Advantage

1. big crushing ratio and large capacity;
2. Low consumption and even granule;
3. simple design and compact structure;
4. modest investment and easy management.

German Type Coarse Powder Crusher

German Type Coarse Powder Crusher

German Type Coarse Powder Crusher

German Type Coarse Powder Crusher

Parameter

Model Length of the rotor(mm) Diameter of the rotor(mm) Rotation speed of the rotor(r/min) Max. input size (mm) Output size(mm) Capacity(t/h) Motor power(KW) Overall Dimension(mm)
CM4008 750 800 800-1000<70 0-3 35-50 75 2130&times;1665&times;1610
CM4012 900 1200 800-1000<90 0-3 75-90 90 2840&times;2100&times;2020
CM4015 1150 1500 550-800<100 0-3 110-132 132 3720&times;2650&times;2540
